TMpro2 SW96 - Honda bikes ECU Keihin-OKI
Memory device is serial eeprom 93c46,93c56,93c66,93c86 SMD8 package or Motorola MCU MPC5602.
For MPC5602 must read and write DATA FLASH area of MPC5602,you can use UPA-USB-S or XPROG-box
For serial eeproms expected file size is 128,256,512 or 2048 bytes.
For MPC5602 expected file size is 65536 bytes.
Use PCF7936 or Silca T14 – JMA TP12 or CN3 transponder.
Written transponder is ready programmed to start bike.
Vehicles equipped with this unit:
Honda: All Honda with HISS system – CBR 600F, CBR 600RR, CBR 900, CBR 1000, CBR 1100F, Gold 2800, NT650V, SH150, SH300, Shadow 750, Silver Wind, Varadero, VT750, VTX1800, X11, Hornet, CB400, CB500X and more…
