Memory device is serial eeprom Seiko S29190 SMD8 package.
Eeprom can be located in 2 different position.
Expected file size is 128 bytes.
Use JMA TPX2 – Errebi TX2 or CN2/CN5 or K-JMD or YS-01 transponder.
Written transponder is ready programmed to start bike.
Note: latest Yamaha immobox Moric DO NOT HAVE serial eeprom, so please check your immobox before purchasing this software.
If there is no serial eeprom, but 16 pin chip TMS3705 you need Tmpro SW 108 - Yamaha bikes immobox Moric type 2.
Vehicles equipped with this unit:
Yamaha: BT1100, FJR, FZR, FZ1, FZ6, FZS, XT, XTR, XTX, XVX, YZF
MBK: Skycruiser 125
